How to Directly Program an Inexpensive ESP8266 WiFi Module

The ESP8266 is the answer to “I want something with Wifi.” Surprisingly, there are a number of engineers and hobbyists who have not heard of this chip or have heard of it but don’t really understand what it is. It’s basically the answer to everything IoT to so many engineering problems that have plagued the hobbyist and commercial world alike.

The chip is a processor with integrated RAM, some ROM, and a WiFi radio, and the only external components you will need are 4 capacitors, a crystal and an external flash! It’s CHEAP, like $4/ea cheap! Or $5 if you want it on a nice, convenient carrier board that includes all these components. The power consumption is reasonable (~200mA)1, the range is insane ~300m2 without directional equipment, and a PCB trace antenna and ~4km if you want to be ridiculous.

One place thing that more people need to know about is how to program directly for this chip. Too many times projects use it as a crutch via the AT commands. Read on and find out how to hello world with just this chip.

Continue reading “How to Directly Program an Inexpensive ESP8266 WiFi Module”

Flashing Chips With A CNC

[Eberhard] needed to flash several hundred ATMegas for a project he was working on. This was a problem, but the task did have a few things going for it that made automation easy. The boards the ‘Megas were soldered to weren’t depanelized yet, and he had a neat and weird bed of nails programming connector. There was also a CNC machine close by. This sounds like the ideal situation for automation, and it turns out the setup was pretty easy.

The boards in question were for FPV/radio control telemetry adapter and thankfully the assembly house didn’t depanelize the 40 PCBs on each board before shipping them out. A very cool ATMega flashing tool handled the electrical connections between the computer and the microcontroller, but a real, live human being was still required to move this flashing tool from one chip to the next, upload the firmware, and repeat the process all over again.

The solution came by putting a few metal pins in the bed of a CNC mill, 3D print an adapter for the flashing tool, and writing a little code to move the flashing tool from one chip to the next. An extremely simple app takes care of moving the programmer to an unflashed chip, uploading the firmware, and continuing on to the next chip.

There’s still some work to be done that would basically tie together the Gcode and AVRdude commands into a single interface, but even now a complete panel of 40 PCBs can be programmed in a little over 10 minutes. You can check out a video of that below.

Continue reading “Flashing Chips With A CNC”

Making Embedded GUI’s Without Code

When the 4D Systems display first arrived in the mail, I assumed it would be like any other touch display – get the library and start coding/debugging and maybe get stuff painted on the screen before dinner. So I installed the IDE and driver, got everything talking and then…it happened. There, on my computer screen, were the words that simply could not exist –  “doesn’t require any coding at all”.

I took a step back, blinked and adjusted my glasses. The words were still there. I tapped the side of the monitor to make sure the words hadn’t somehow jumbled themselves together into such an impossible statement. But the words remained…   doesn’t.require.any.coding.at.all.

Continue reading “Making Embedded GUI’s Without Code”

UTF-8 – “The most elegant hack”

While it may not look like much, the image above is a piece of the original email where [Ken Thompson] described what would become the implementation of UTF-8. At the dawn of the computer age in America, when we were still using teletype machines, encoding the English language was all we worried about. Programmers standardized on the ASCII character set, but there was no room for all of the characters used in other languages. To enable real-time worldwide communication, we needed something better. There were many proposals, but the one submitted by [Ken Thompson] and [Rob ‘Commander’ Pike] was the one accepted, quite possibly because of what a beautiful hack it is.

[Tom Scott] did an excellent job of describing the UTF-8. Why he chose to explain it in the middle of a busy cafe is beyond us, but his enthusiasm was definitely up to the task. In the video (which is embedded after the break) he quickly shows the simplicity and genius of ASCII. He then explains the challenge of supporting so many character sets, and why UTF-8 made so much sense.

We considered making this a Retrotechtacular, but the consensus is that understanding how UTF-8 came about is useful for modern hackers and coders. If you’re interested in learning more, there are tons of links in this Reddit post, including a link to the original email.

Continue reading “UTF-8 – “The most elegant hack””

Update: McHck’s self flashing rig

A few weeks ago we featured the McHck project (pronounced McHack), a $5 Cortex M4 based platform which can be directly plugged into one’s computer. Recently, [Simon] announced that he made a firmware allowing a McHck to behave as a SWD adapter and also detailed his flashing rig.

Therefore, those who’d want to build their own McHck would only need to borrow an SWD programmer once to get started. When the first platform has been programmed with the SWD firmware, it can be used to flash and debug applications on the second McHck. Consequently, the microcontroller flashing rig [Simon] designed (shown in the picture above) is based on this. The few core elements are a TQFP48 ZIF programming socket, a push button and two LEDs. Simply push the Kinetis in the programming socket, close it and press the button. Success of the operation is indicated by the two LEDs. [Simon] used the Ragel State Machine Compiler to generate his flashing program and all the code he made can be downloaded from his github.

If you missed the original McHck post now’s your chance to go back and see what it is all about.

Retrotechtacular: How I wrote Pitfall for the Atari 2600

how-I-programmed-pitfall

This week we’re taking another departure from the ordinarily campy videos featured in the Retrotechtacular section. This time around the video is only two years old, but the subject matter is from the early 1980’s. [David Crane], designer of Pitfall for the Atari 2600 gave a talk at the 2011 Game Developer’s Conference. His 38-minute presentation rounds up to a full hour with the Q&A afterwards. It’s a bit dry to start, but he hits his stride about half way through and it’s chock-full of juicy morsels about the way things used to be.

[David] wrote the game for Activision, a company that was started after game designers left Atari having been told they were no more important  than assembly line workers that assembled the actual cartridges. We wonder if any heads rolled at Atari once Pitfall had spent 64-weeks as the number one worldwide selling game?

This was a developer’s panel so you can bet the video below digs deep into coding challenges. Frame buffer? No way! The 2600 could only pump out 160 pixels at once; a single TV scan line. The programs were hopelessly synced with the TV refresh rate, and were even limited on how many things could be drawn within a single scan line. For us the most interesting part is near the end when [David] describes how the set of game screens are nothing more than a pseudo-random number generator with a carefully chosen seed. But then again, the recollection of hand optimizating the code to fit a 6k game on a 4k ROM is equally compelling.

If you like this you should take a look at an effort to fix coding glitches in Atari games.

Continue reading “Retrotechtacular: How I wrote Pitfall for the Atari 2600″

The meaning of being a hard-core hacker from a 1985 recollection

6502-hand-assembling-and-programming

Gather ’round children, we’re about to hear a story about the good old days. Except that this is really more of a horror story of what it used to be like as a code monkey. [John Graham-Cumming] shares his experience programming a 6502-based KIM-1 machine back in 1985. Simple, right? The caveat being that there was no assembler or hardware for loading the finished code!

The machine in question was a label application tool for a production line. You know, product goes in bottle, label gets slapped on the side. But the slapping needed to be perfect because consumers shy away from packaging that looks shoddy. Computer control would end up being far superior than the mechanical means the factory had been using because it simplifies the ability to adjust calibration and other parameters. [John] started from square one by interfacing the KIM-1 with the existing hardware. It has a hex keyboard which is how the program was entered into the device. But first he wrote the software on sheets of notebook paper like the one seen above. It includes his hand assembled code, which was then typed in on the keypad. Kind of makes you appreciate all the tools you take for granted (like Eclipse), huh?

[via Reddit]
