Overwhelmed By Odd Inputs: The Contest Winners And More

July 13, 2022 by 1 Comment

The Odd Inputs and Peculiar Peripherals Contest wrapped up last week, and our judges have been hard at work sifting through their favorite projects. And this was no easy task – we had 75 entries and so many of them were cool in their own right that all we can say is go check them all out. Really.

But we had to pick winners, not the least because Digi-Key put up three $150 gift certificates. So without further ado, here are the top three projects and as many honorable mentions as you have fingers and toes – if you don’t count your thumbs.

The Prize Winners

Keybon should be a mainstream commercial product. It’s a macro keypad with an OLED screen per key. It talks to an application on your desktop that detects the program that you currently have focused, and adapts the keypress action and the OLED labels to match. It’s a super-slick 3D-printed design to boot. It’s the dream of the Optimus Maximus, but made both DIY and significantly more reasonable as a macro pad. It’s the coolest thing to have on your desk, and it’s a big winner!

On the ridiculous side of keyboards, meet the Cree-board. [Matt] says he got the idea of using beefy COB LEDs as keycaps from the bad pun in the name, but we love the effect when you press down on the otherwise blinding light – they’re so bright that they use your entire meaty finger as a diffuser. Plus, it really does look like a keypad of sunny-side up eggs. It’s wacky, unique, and what’s not to love about that in a macropad?

Finally, [Josh EJ] turned an exercise bike into a wireless gamepad, obliterating the choice between getting fit and getting high scores by enabling both at the same time. An ESP32-turned-Bluetooth-gamepad is the brains, and he documents in detail how he hooked up a homebrew cadence sensor, used the heart-rate pads as buttons, and even added some extra controls on top. Watching clips of him pedaling his heart out in order to push the virtual pedal to the metal in GRID Autosport, we only wish he were screaming “vroooom”. Continue reading “Overwhelmed By Odd Inputs: The Contest Winners And More” →

Bringing Some Discipline To An SDR Transmitter

July 13, 2022 by 16 Comments

The proliferation of software-defined radio (SDR) technology has been a godsend for RF hobbyists. SDR-based receivers and transmitters have gotten so cheap that you’ve probably got a stick or two lying around your bench right now — we can see three from where we sit, in fact.

But cheap comes at a price, usually in the form of frequency stability, which can be prohibitive in some applications — especially amateur radio, where spectrum hygiene is of the utmost concern. So we were pleased to see [Tech Minds] tackle the SDR frequency stability problem by using a GPS-disciplined oscillator. The setup uses an ADALM-PLUTO SDR transceiver and a precision oscillator from Leo Bodnar Electronics. The oscillator can be programmed to output a rock-solid, GPS-disciplined signal over a wide range of frequencies. The Pluto has an external oscillator input that looks for 40 MHz, which is well within the range of the GPSDO.

Setup is as easy as plugging the oscillator’s output into the SDR’s external clock input using an SMA to UFL jumper, and tweaking the settings in the SDR and oscillator. Not all SDRs will have an external clock input, of course, so your mileage may vary. But if your gear is suitably equipped, this looks like a great way to get bang-on frequency — the video below shows just how much the undisciplined SDR can drift.

Like any good ham, [Tech Minds] is doing his bit to keep his signals clean and on target. His chief use case for this setup will be to work QO-100, amateur radio’s first geosynchronous satellite repeater. We’ve got to say that we hams living on the two-thirds of the globe not covered by this satellite are just dying to get a geosynchronous bird (or two) of our own to play with like this.

Continue reading “Bringing Some Discipline To An SDR Transmitter” →

You Wouldn’t 3D Print A House, Would You?

July 13, 2022 by 66 Comments

Most houses built in the US today are platform construction: skinny two-by-fours are stacked and layered to create walls with studs. Each floor is framed on top of the other. It is fast, relatively cheap, and easy to learn how to do. However, it is not without drawbacks. Some estimates put the amount of waste generated per square foot (0.09 m2) at around 3.9 lbs (1.8 kg).

Timber framing is an older style where giant beams are used to create the structure of the house. Each timber is hand-carved and shaped, requiring skill and precision. Some cabins are still built this way because it is easy to source the timber locally and cutting into big logs is less work than cutting into lots of small logs. It’s relatively ecologically friendly, but slow and skilled-labor intensive.

We live in a world where there is a vast need for cheaper, faster, more eco-friendly housing, but finding a solution that can tick all the boxes is fiendishly difficult. Can 3D-printed housing accomplish all three of those goals? We’re not there yet, but we’re working on it.

Continue reading “You Wouldn’t 3D Print A House, Would You?” →

Tio Is A Serial Terminal For Us

July 13, 2022 by 31 Comments

With Linux and the serial port there is good news and there is bad news. The good news is that Linux has great support for serial hardware of all sorts and a host of tools for accessing the serial port. That’s important when you use a lot of serial-like devices like Arduinos with USB ports and the like. The bad news is that most of the terminal software is made to accommodate the days when a computer had real serial terminals and modems with people interacting with them. We bet that’s why [lundmar] developed tio, a serial device I/O tool for people like us.

Honestly, how many times have you needed Zmodem file transfers and recognition of the DCD signal to detect an incoming connection? Sure there are many other programs that will do the job, but tio brings a clean simplicity along with functionality that embedded developers need.

The software will support arbitrary devices, show statistics, and give you control of the RS232 lines. There’s support for delayed characters and lines, useful if you are dealing with a super simple device with no handshaking. There’s also hex support and many ways to log data and statistics. We especially like that it can automatically reconnect which is a great feature.

Of course, you want some terminal features and tio includes those. For example, you can elect to have local echo turned on or map characters so that, for example, a carriage return turns into a carriage return and a line feed. You can use command line options to set up most items including features like redirecting to a network socket. Other commands inside the program — by default, triggered by Control+T — let you do things like send a break, toggle handshaking lines, and more.

You might think the serial port is dead, but it really just transformed into a USB port.  Of course, like everything else these days, you can also get your terminal in the browser.

A Guitar From Scratch

July 13, 2022 by 15 Comments

You can pursue your dreams of rock superstardom with any guitar, be it from an expensive luthier, a pawn shop, or a mail order catalog. But to join the ranks of rock greats there’s one way to have a truly special instrument, which is to build it yourself. [Bensoncraft] may not be [Bryan May]’s dad or indeed [Eddie van Halen], but he has at least joined the exclusive ranks of home made guitar builders with his video “Guitar from scratch: hard mode“.

It’s a fairly long video and we’ve placed it below the break, but a compelling one as we learn just how many operations go into making an electric guitar. When he says hard mode he’s not joking, there are no pre-made parts save for the strings and he’s not following a set of plans. Everything including the tuners and pickups are made from scratch, but for a non-guitar-player it’s she sheer number of different pieces of wood that go into making the solid body and neck of the instrument that’s so interesting. Even if you’ll never make a guitar you should watch it.

We’ve never seen a guitar build quite like this one before, but we have brought you a 3D printed guitar body, and neck.

Continue reading “A Guitar From Scratch” →

It’s A Bird! It’s A Plane! It’s… A Live Air Traffic Plane Spotting Simulation

July 12, 2022 by 5 Comments

Plane spotting has been a hobby of aviation enthusiasts for generations. Hanging out by the airport, watching aircraft come and go, maybe even listening to Air Traffic Control on a scanner from your local Radio Shack. Yep- we’ve been there, and it can be a lot of fun! But how can those of us who don’t live near a major controlled airport keep up on the action? As demonstrated by the [Information Zulu] YouTube channel’s Live Stream, seen below the break, the action may be closer than you think!

Aircraft on approach to LAX- Virtually

By using publicly available information, software, and some ingenuity, [Information Zulu] has created a live simulation of Los Angeles International Airport (LAX) for your simulated plane spotting pleasure. Aircraft positional data is gained through an ADSB receiver and piped into a the flight simulator software with a Traffic Injection Addon, and the simulator itself is used to properly place aircraft, set the weather, and even the correct aircraft types and liveries. Setting off the illusion of a real plane spotting adventure is the live Air Traffic Control radio chatter!

We love the creativity that went into not just making all of the software available, but in combining it into a cohesive product that can be viewed 24/7 on YouTube that, if you squint just right, could be mistaken for a view of the real thing.

If you’re not familiar with ADSB and how it’s used to track aircraft in such a way that anybody can receive it with the right equipment, check out this beginner’s course on ADSB from a few years back!

Continue reading “It’s A Bird! It’s A Plane! It’s… A Live Air Traffic Plane Spotting Simulation” →

Build Your Own… Whatever

July 12, 2022 by 23 Comments

You can read all about making, say, a bookshelf or bowling, but unless you’ve actually done it, you don’t really know how it works. That’s the idea behind [codecrafters-io] Build-Your-Own-X GitHub repository. It is a collection of software projects from around the Web that offer “step-by-step guides for recreating our favorite technologies from scratch.”

What can you find there? Well, how about writing your own version of Git itself? Or maybe you’d like to dive into a physics engine, blockchain code, or a text editor. Then there’s our favorite: an operating system.

Continue reading “Build Your Own… Whatever” →
